Solar panel

18V solar panels lower than 200W(no-load21.5V)

Inverter

DC12V-AC220V ， 500W Pure sine

Output volt

DC12V x 8 output ports，Max output current：5A；

USB 5V 1A x2output ports；

AC 220Vx2 output ports，Max output current：2A

Internal battery

12V45AH~65AH，maintenance-free lead-acid battery

Charging time

Depends on recharge method

Recharging time

Depends on loading power

Rated charging current

＜20A

Rated discharge current

5A

System volt

12V

No-load loss

<50mA

Overvoltage

14.4V

Boost voltage

15V

undervoltage

11.6V

Overdischarge volt

10.5V

Control mode

recharge；PWM(pulse width modulation)

Working temperature

Overload/short circuit protection

10ms Response

Guard circuit：

Overload/short circuit protection

Burn the fuse
